Quad-Core Rockchip RK3188 Android embedded computer
April 20, 2018
The EM3188 SBC is powered by Rochchip RK3188 processor with WiFi, 3G and GPS module, and designed for Tablet, set-top boxes and other digital multimedia applications.
The Boardcon EM3188 SBC comes with Ethernet, CAN, RS485 and other basic ports such as USB2.0 OTG, dual USB2.0 HOST, dual DB9, a 3.5mm audio jack and a microSD card for additional storage. This RK3188 SBC features RK616 chipset(optional) that includes two RGB display input interface with double data rate. With the internal MUX function, it can output 1080P HDMI signal to TV and output RGB/LVDS signal to TFT panel. In this case, EM3188 can support dual panel(TV and TFT)display.
EM3188 SBC Specifications
- Processor: Rockchip RK3188, Quad-Core ARM Cortex-A9 @ 1.6GHz
- RAM: 1GB DDR3
- eMMC Flash: 4GB
- Interface: 1x Ethernet, 2x USB Host, 1x USB OTG, CAN, RS485, HDMI, 2x UART(DB9/Header), Micro SD, SIM slot, PCI-E, Headphone, SPK, LVDS, GPIO, Camera, 2x TTL_LCD
- Operating system: Android5.1
- Optional modules: WiF&Bluetooth, 3G, Camera, GPS
- Dimension: 161mm x 116mm
